-Cảm biến hình ảnh: 1/2.5 inch CMOS.
-Chuẩn nén hình ảnh: H.265, H.265+, H.264+, H.264.
-Ống kính: 2.8mm, 4mm, 6mm, 8mm, 12mm (tùy chọn).
-Độ phân giải camera ip: 8.0 Megapixel.
-Tầm quan sát hồng ngoại: 80 mét.
-Hỗ trợ khe cắm thẻ nhớ Micro SD/SDHC/SDXC dung lượng lên đến 128GB.
-Chức năng báo động khi có đột nhập, chuyển động, vượt hàng rào ảo…
-Chức năng lọc nhiễu kỹ thuật số 3D DNR (Dynamic Noise Reduction).
-Chức năng chống ngược sáng Digital WDR (Wide Dynamic Range).
-Tiêu chuẩn chống thấm nước và bụi: IP66 (thích hợp sử dụng trong nhà và ngoài trời).
-Nguồn điện cung cấp: 12VDC.
-Chức năng cấp nguồn qua mạng PoE.
-Dễ dàng giám sát qua điện thoại di động, iPad, iPhone…
-Phần mềm giám sát và tên miền miễn phí…
Đặc tính kỹ thuật
Camera
Image Sensor 1/2.5 inch Progressive Scan CMOS
Min. Illumination Color: 0.01 lux @ (F1.2, AGC ON), 0 lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Support
Lens 2.8 mm, horizontal field of view: 102°
4 mm, horizontal field of view: 79°
6 mm, horizontal field of view: 50°
8 mm, horizontal field of view: 40°
12 mm, horizontal field of view: 23°
Lens Mount M12
Iris F2.0
Day & Night IR cut filter
Wide Dynamic Range 120dB
Digital noise reduction 3D-DNR
3-Axis Adjustment (bracket) Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
Compression Standard
Video Compression Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type Main Profile/High Profile
H.264+ Support
H.265 Type Main Profile
H.265+ Support
Video bit rate 32 Kbps to 16 Mbps
Max. Image Resolution 3840 x 2160
Main Stream 50Hz: 20 fps (3840 x 2160), 25 fps (2560 x 1920, 2560 x 1440, 1920 x 1080, 1280 x 720)
60Hz: 20 fps (3840 x 2160), 30 fps (2560 x 1920, 2560 x 1440, 1920 x 1080, 1280 x 720)
Sub Stream 50Hz: 25fps (640 x 360, 352 x 288)
60Hz: 30fps (640 x 360, 352 x 240)
Third Stream 50Hz: 25fps (1280 x 720, 640 x 360, 352 x 288)
60Hz: 30fps (1280 x 720, 640 x 360, 352 x 240)
Image Enhancement BLC/3D-DNR
Image Settings Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web
browser and client software
ROI (Region of Interest) Support 1 fixed region for mainstream and sub stream separately
Network
Network Storage Support microSD/ SDHC/ SDXC card (128G) local storage, NAS (NFS, SMB/ CIFS), ANR
Alarm Trigger Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login,HDD full, HDD error
Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Standard ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI
General Function One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark,IP Address Filter
Interface
Communication Interface 1 RJ45 10M/100Mbps Ethernet interface
On-board storage Built-in Micro SD/SDHC/SDXC slot, up to 128GB
Smart Feature-set
Behavior Analysis Line crossing detection, intrusion detection, unattended baggage detection, object removaldetection
Line Crossing Detection Cross a pre-defined virtual line, up to 1 pre-defined virtual lines supported
Intrusion Detection Enter and loiter in a pre-defined virtual region, up to 1 pre-defined virtual regions supported
Object Removal Detection Objects removed from the pre-defined region, such as the exhibits on display
Unattended Baggage Detection Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Face Detection Human face appears in the image can be detected and trigger linkage method
General
Operating Conditions -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply 12VDC ± 25%
PoE (802.3af 42.5 – 57V, class 3), 9W
Power Consumption Max. 12W
Weather Proof IP67
IR Range 80 meters
Dimensions Φ104.8 x 299.7 mm
Weight Camera ip 1200g
-Bảo hành: 24 tháng.
