– Cảm biến hình ảnh: 1/2.9 inch Progressive Scan CMOS.
– Độ phân giải camera ip: 6.0 Megapixel.
– Chuẩn nén hình ảnh: H.265+/H.265/H.264+/H.264/MJPEG.
– Ống kính: 4mm (tùy chọn 2.8mm, 6mm).
– Ghi hình: 3072 × 2048@20 fps.
– Chống ngược sáng WDR 120dB.
– Độ nhạy sáng Màu: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON) 0 lux với hồng ngoại.
– Công nghệ hồng ngoại EXIR 2.0.
– Tầm quan sát hồng ngoại: 30 mét.
– Chức năng quan sát ngày đêm ICR.
– Tính năng giảm nhiễu số 3D DNR.
– Tích hợp thẻ nhớ SD/SDHC/SDXC slot.
– Dễ dàng giám sát qua điện thoại di động, iPad, iPhone…
– Phần mềm giám sát và tên miền miễn phí.
– Nguồn điện: 12VDC & PoE.
– Kích thước: Φ 70 × 155 mm.
– Trọng lượng: 410 g.
Đặc tính kỹ thuật
Model DS-2CD2063G0-I
Camera
Image Sensor 1/2.9 inch Progressive Scan CMOS
Min. Illumination Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Day & Night IR Cut Filter
Digital Noise Reduction 3D DNR
WDR 120dB
3-Axis Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
Focal Length 2.8/4/6/8 mm
Aperture F2.0
Focus Auto
FOV 2.8 mm, horizontal FOV: 97°, vertical FOV: 63°, diagonal FOV: 120°
4 mm, horizontal FOV: 78°, vertical FOV: 50°, diagonal FOV: 97°
6 mm, horizontal FOV: 60°, vertical FOV: 39°, diagonal FOV: 75°
8 mm, horizontal FOV: 39.5°, vertical FOV: 26°, diagonal FOV: 48°
Lens Mount M12
IR
IR Range Up to 30 m
Wavelength 850 nm
Compression Standard
Video Compression Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 Type Main Profile/High Profile
H.264+ Main stream supports
H.265 Type Main Profile
H.265+ Main stream supports
Video Bit Rate 32 Kbps to 16 Mbps
Smart Feature-set
Behavior Analysis Line crossing detection, intrusion detection
Face Detection Yes
Region of Interest Support 1 fixed region for main stream and sub-stream
Max. Resolution 3072 × 2048
Main Stream 50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×720)
60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 ×720)
Sub-Stream 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream 50Hz: 25fps(1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps(1280 × 720, 640 × 360, 352 × 240)
Image Enhancement BLC/3D DNR
Image Settings Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night Switch Day/Night/Auto/Schedule
Network
Network Storage Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Firmware Version V5.5.3
API ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View Up to 6 channels
Up to 32 users
3 levels: Administrator, Operator and User
Client iVMS-4200, Hik-Connect, iVMS-5200
Web Browser IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage Built-in microSD/SDHC/SDXC slot, up to 128 GB
SVC H.264 and H.265 encoding support
Reset Button Yes
General
Operating Conditions -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, Φ 5.5mm coaxial power plug PoE(802.3af, class 3)
Power Consumption and Current 12 VDC, 0.4 A, max. 6W
PoE: (802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 7.5W
Protection Level IP67
Material Metal
Dimensions Camera: Φ 70 × 155 mm
Package: 216 × 121 × 118 mm
Weight Camera: approx. 410 g
– Bảo hành: 24 tháng.
